| Type |
1/1.8” CCD | | Effective Pixels | Approx.5.0M | | Total Pixels | Approx.5.3M | | Aspect Ratio | 4:3 | | Colour Filter Type | Primary Colour | | Type | DIGIC with iSAPS technology | | Focal Length | 7.4 – 22.2 mm (35mm film equivalent: 36 – 108mm) | | Zoom | Optical 3x, digital approx. 4.1x, combined approx. 12x | | Maximum f/number | f/2.8 – f/4.9 | | Construction | 7 elements in 5 groups (2 aspherical elements) | | Type | TTL | | AF System / Points | 9-point AiAF, 1-point AF (Fixed centre) | | AF Modes | Normal, Macro, Infinity | | Selected AF Point Display | Indicated on rear LCD panel | | AF Lock | Locked when shutter button is pressed half way | | AF Assist Beam | Yes | | Closest Focusing Distance | 5cm | | Metering Modes | Evaluative, Centre-weighted average, Spot (centre) | | AE Lock | Yes | | Exposure Compensation | +/- 2 EV in 1/3 stop increments | | ISO Speed Equivalent | AUTO, 50, 100, 200, 400 | | Type | Mechanical shutter & electronic shutter | | Speed | 15 – 1/2,000 sec | (Slow Shutter speeds of 1 sec. and more, available in Long Shutter Mode only. Shutter speeds of 1.3 sec. and more operate with noise reduction). | | Type | TTL | | Settings | Auto, Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Custom | | Type | sRGB | | Viewfinder | Real-image zoom, optical viewfinder | | Eyepoint | 16mm | | Monitor | 1.5” P-Si TFT, approx. 118,000 pixels | | Coverage | 100% | | Brightness | Adjustable to one of fifteen levels | | Modes | Auto, Manual Flash On / Off | | Slow Sync Speed | Yes | | Red-eye Reduction | Yes | | Flash Exposure Lock | Yes | | Built-in Flash Range | 46cm-3.5m (W) / 46cm - 2.0m (T), 30 - 46cm (Macro) (at ISO AUTO equivalent) | | Modes | Auto, Manual, Long Shutter, Macro, Infinity, Stitch Assist, Movie | | Photo Effects | Vivid, Neutral, Low Sharpening, Sepia, Black & White | | Drive Modes | Single, Continuous | | Continuous Shooting | High Speed at approx. 2.2 fps¹ (speed maintained for up to 14 images) | Normal at approx. 1.5 fps¹ (speed maintained for up to 17 images)² | | Image Size | (L)2592 x 1944, (M1)2048 x 1536, (M2)1600 x 1200, (S)640 x 480 | | Compression | Superfine, Fine, Normal | | Movies | (L)640 x 480, 10fps (M)320 x 240, (S)160 x 120, 15fps | | Movie Length | Up to 3mins, (320x240, 160x120)² | Upto 30sec. (640 x 480)² | | Still Image Format | JPEG (Exif 2.2 [Exif Print] compliant) / Design rule for Camera File system, Digital Print Order Format [DPOF] Version 1.1 compliant | | Movies | AVI [Motion JPEG + WAVE (monaural)] | | Sound Files | WAVE (monaural) | | Canon Printers | Canon Compact Photo Printers and Bubble Jet Printers with the direct print function. (ID Photo Print, Movie Print supported on CP printers only) | | PictBridge | Yes | | My Camera | Start-up image and camera sounds customisation | | Sound Memo | Up to 60 sec per image | | Intelligent Orientation Sensor | Yes | | Histogram | Yes | | Playback Zoom | 2x – 10x | | Image Erase Protection | Single image | | Image Erase | Single image, All | | Self Timer | Approx. 2 or 10 sec. | | Menu Categories | (1) Recording Menu | (2) Playback menu | (3) Set-up menu | (4) My camera menu | (5) Function menu | | Menu Languages | English, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified Chinese, Japanese | | Firmware Update | Update possible by the user. | | Computer | USB (Mini-B, PTP) | | Other | A/V output (PAL/NTSC) | | Type | CompactFlash Type I | | PC | Windows 98(including SE) / 2000 / Me / XP | | Macintosh | OS 9.0 – 9.2, OS X v10.1 / v10.2 | | Browsing & Printing | ZoomBrowser EX (PhotoRecord) / ImageBrowser | | Other | PhotoStitch | | Drivers | TWAIN (Windows 98 / 2000), WIA (Windows Me) | | Image Manipulation | ArcSoft PhotoImpression, ArcSoft VideoImpression | | Batteries | Rechargeable Li-ion Battery NB-1LH (battery and charger supplied) | | Battery Life | Approx. 190 shots (LCD monitor on) | Approx. 440 shots (LCD monitor off) | Approx. 140 min. (Playback) | | Power Saving | Power turns off after 10, 20, 30sec. 1, 2, 3mins. | | | | | | | | | | | | | | Body Materials | Metal body | | Operating Environment | 0 – 40 °C, 10 – 90% humidity | | Dimensions | 87.0 x 57.0 x 27.8 mm | | Weight (body only) | Approx. 185g | |
|
|
